It can be instructive to visualize the distribution of trees in a spatial ‘landscape’. This can be a helpful means to address whether discrete islands of trees exist, or whether analytical runs have converged. Such analysis is relatively simple to conduct, but a few common oversights can mislead interpretation.

Tree space mapping and analysis is made simple with the Shiny app included in the ‘TreeDist’ R package. Simply install R or RStudio, then copy the code below into the R command line:

```
install.packages('TreeDist')
TreeDist::MapTrees()
```

This will allow you to conduct and evaluate basic tree space mappings from tree lists saved in most common file formats; see an outline of the basic functionality. To avoid misinterpreting tree space, it’s worth having a broad idea of what an analysis involves, and some potential pitfalls.

Here’s an example analysis of a series of 200 trees from an ordered list. The list corresponds to a mixed-base representation of trees (see `TreeTools::as.TreeNumber()`

), so is expected to contain some structure as we jump from one ‘class’ of tree to another. Let’s see whether we can visualize and corroborate this structure.

First we’ll generate the trees, and load some colours with which we might identify them.

```
library('TreeTools', quietly = TRUE, warn.conflicts = FALSE)
treeNumbers <- c(1:220)
trees <- as.phylo(treeNumbers, 8)
spectrum <- hcl.colors(220, 'plasma')
treeCols <- spectrum[treeNumbers]
```

Now we need to calculate the distance between each pair of trees in our list. The choice of distance metric is important (Smith, 2021). The widely used Robinson–Foulds distance is, unfortunately, unsuitable for tree space analysis. The clustering information distance (Smith, 2020) is a reliable alternative that is fast to calculate:

```
library('TreeDist')
distances <- ClusteringInfoDistance(trees)
```

The reader is encouraged to repeat the exercise with other distances:

```
distances <- RobinsonFoulds(trees)
distances <- PhylogeneticInfoDistance(trees)
distances <- as.dist(Quartet::QuartetDivergence(
Quartet::ManyToManyQuartetAgreement(trees), similarity = FALSE))
```

Then we need to reduce the dimensionality of these distances. We’ll start out with a 12-dimensional mapping; if needed, we can always drop higher dimensions.

Principal coordinates analysis is quick and performs very well:

`mapping <- cmdscale(distances, k = 12)`

Alternative mapping methods do exist, and sometimes give slightly better mappings. `isoMDS()`

performs non-metric multidimensional scaling (MDS) with the Kruskal-1 stress function (Kruskal, 1964):

```
kruskal <- MASS::isoMDS(distances, k = 12)
mapping <- kruskal$points
```

whereas `sammon()`

, one of many metric MDS methods, uses Sammon’s stress function (Sammon, 1969):

```
sammon <- MASS::sammon(distances, k = 12)
mapping <- sammon$points
```

That’s a good start. It is tempting to plot the first two dimensions arising from this mapping and be done:

A quick visual inspection suggests at least two clusters, with the possibility of further subdivision of the brighter trees. But visual inspection can be highly misleading (Smith, 2021). We must take a statistical approach. A combination of partitioning around medoids and hierarchical clustering with minimax linkage will typically find a clustering solution that is close to optimal, if one exists (Smith, 2021).

```
possibleClusters <- 2:10
pamClusters <- lapply(possibleClusters, function (k) cluster::pam(distances, k = k))
pamSils <- vapply(pamClusters, function (pamCluster) {
mean(cluster::silhouette(pamCluster)[, 3])
}, double(1))
bestPam <- which.max(pamSils)
pamSil <- pamSils[bestPam]
pamCluster <- pamClusters[[bestPam]]$cluster
hTree <- protoclust(distances)
hClusters <- lapply(possibleClusters, function (k) cutree(hTree, k = k))
hSils <- vapply(hClusters, function (hCluster) {
mean(cluster::silhouette(hCluster, distances)[, 3])
}, double(1))
bestH <- which.max(hSils)
hSil <- hSils[bestH]
hCluster <- hClusters[[bestH]]
plot(pamSils ~ possibleClusters,
xlab = 'Number of clusters', ylab = 'Silhouette coefficient',
ylim = range(c(pamSils, hSils)))
points(hSils ~ possibleClusters, pch = 2)
legend('topright', c('PAM', 'Hierarchical'), pch = 1:2)
```

Silhouette coefficients of < 0.25 suggest that structure is not meaningful; > 0.5 denotes good evidence of clustering, and > 0.7 strong evidence (Kaufman & Rousseeuw, 1990). The evidence for the visually apparent clustering is not as strong as it first appears. Let’s explore our two-cluster hierarchical clustering solution anyway.

`cluster <- hClusters[[2 - 1]]`

We can visualize the clustering solution as a tree:

```
class(hTree) <- 'hclust'
par(mar = c(0, 0, 0, 0))
plot(hTree, labels = FALSE, main = '')
points(seq_along(trees), rep(1, length(trees)), pch = 16,
col = spectrum[hTree$order])
```

Another thing we may wish to do is to take the consensus of each cluster:

```
par(mfrow = c(1, 2), mar = rep(0.2, 4))
col1 <- spectrum[mean(treeNumbers[cluster == 1])]
col2 <- spectrum[mean(treeNumbers[cluster == 2])]
plot(consensus(trees[cluster == 1], p = 0.5),
edge.color = col1, edge.width = 2, tip.color = col1)
plot(consensus(trees[cluster == 2], p = 0.5),
edge.color = col2, edge.width = 2, tip.color = col2)
```

Here, we learn that the two clusters are distinguished by the position of `t7`

.

Now let’s evaluate whether our map of tree space is representative. First we want to know how many dimensions are necessary to adequately represent the true distances between trees. We hope for a trustworthiness × continuity score of > 0.9 for a usable mapping, or > 0.95 for a good one.

```
txc <- vapply(seq_len(ncol(mapping)), function (k) {
newDist <- dist(mapping[, seq_len(k)])
MappingQuality(distances, newDist, 10)['TxC']
}, 0)
plot(txc, xlab = 'Dimension')
abline(h = 0.9, lty = 2)
```

We are going to need at least five dimensions to adequately represent the distances between trees.

To help establish visually what structures are more likely to be genuine, we might also choose to calculate a minimum spanning tree:

`mstEnds <- MSTEdges(distances)`

Let’s plot the first five dimensions of our tree space, highlighting the convex hulls of our clusters:

```
nDim <- which.max(txc > 0.9)
plotSeq <- matrix(0, nDim, nDim)
plotSeq[upper.tri(plotSeq)] <- seq_len(nDim * (nDim - 1) / 2)
plotSeq <- t(plotSeq[-nDim, -1])
plotSeq[nDim * 1:3] <- (nDim * 2) + 1:3
layout(plotSeq)
par(mar = rep(0.1, 4))
for (i in 2:nDim) for (j in seq_len(i - 1)) {
# Set up blank plot
plot(mapping[, j], mapping[, i], ann = FALSE, axes = FALSE, frame.plot = TRUE,
type = 'n', asp = 1, xlim = range(mapping), ylim = range(mapping))
# Plot MST
apply(mstEnds, 1, function (segment)
lines(mapping[segment, j], mapping[segment, i], col = "#bbbbbb", lty = 1))
# Add points
points(mapping[, j], mapping[, i], pch = 16, col = treeCols)
# Mark clusters
for (clI in unique(cluster)) {
inCluster <- cluster == clI
clusterX <- mapping[inCluster, j]
clusterY <- mapping[inCluster, i]
hull <- chull(clusterX, clusterY)
polygon(clusterX[hull], clusterY[hull], lty = 1, lwd = 2,
border = '#54de25bb')
text(mean(clusterX), mean(clusterY), clI, col = '#54de25bb', font = 2)
}
}
# Annotate dimensions
plot(0, 0, type = 'n', ann = FALSE, axes = FALSE)
text(0, 0, 'Dimension 2')
plot(0, 0, type = 'n', ann = FALSE, axes = FALSE)
text(0, 0, 'Dimension 3')
plot(0, 0, type = 'n', ann = FALSE, axes = FALSE)
text(0, 0, 'Dimension 4')
```

Our clusters, so distinct in dimension 1, overlap strongly in every other dimension. The fact that the minimum spanning tree moves between clusters also underlines the fact that they are not as well defined as they appear by eye.

Note that cluster membership, as well as the precise shape of tree space, is a function of the tree distance metric. The phylogenetic information distance recovers a different pair of clusters, which may not correspond to those that are most apparent from a simple visual inspection of the two-dimensional tree space plot:

It is tempting to compare the size of clusters by calculating the area of convex hulls on a two-dimensional mapping. However, mapped areas do not necessarily correspond to true hypervolumes.

Accuracy may be improved by comparing higher dimensions of projections using the “hypervolume” package, though the same considerations apply (Blonder et al., 2018). Interpretation of overlap statistics is detailed in Mammola (2019).

`hypervolumeInstalled <- requireNamespace('hypervolume', quietly = TRUE)`

```
## Error in dyn.load(dynlib <- getDynlib(dir)) :
## unable to load shared object '/Users/runner/work/_temp/Library/rgl/libs/rgl.so':
## dlopen(/Users/runner/work/_temp/Library/rgl/libs/rgl.so, 6): Library not loaded: /opt/X11/lib/libGLU.1.dylib
## Referenced from: /Users/runner/work/_temp/Library/rgl/libs/rgl.so
## Reason: image not found
```

```
## Warning: Loading rgl's DLL failed.
## This build of rgl depends on XQuartz, which failed to load.
## See the discussion in https://stackoverflow.com/a/66127391/2554330
```

`## Warning: Trying without OpenGL...`

```
if (hypervolumeInstalled) {
capture.output({
library('hypervolume')
hv1 <- hypervolume_gaussian(pid_mapping[pid_cluster == 1, 1:3])
hv2 <- hypervolume_gaussian(pid_mapping[pid_cluster == 2, 1:3])
hv_dist <- hypervolume_distance(hv1, hv2)
hyperset <- hypervolume_set(hv1, hv2, check.memory = FALSE)
hv_overlap <- hypervolume_overlap_statistics(hyperset)
}) -> XX
hv_dist
hv_overlap
} else {
print("Install the 'hypervolume' package to run this example")
}
```

`## [1] "Install the 'hypervolume' package to run this example"`

An alternative approach to visualizing tree space is to create emergent self-organizing maps (Kohonen, 1982; Thrun, Lerch, Lötsch, & Ultsch, 2016; Ultsch, 2003), which map high-dimensional data into two dimensions, then add a third dimension to indicate distance between data points: nearby points occur in valleys, and are separated by ridges from more distant data points.

```
umatrixInstalled <- requireNamespace('Umatrix', quietly = TRUE)
if (umatrixInstalled) {
map <- Umatrix::esomTrain(as.matrix(distances), Key = seq_along(trees),
Epochs = 5, # Increase for better results
Lines = 42,
Columns = 42,
Toroid = FALSE)
Umatrix::plotMatrix(Matrix = map$Umatrix,
Toroid = FALSE, FixedRatio = TRUE,
TransparentContours = FALSE, Clean = TRUE) +
ggplot2::geom_point(data = data.frame(x = map$BestMatches[, 3],
y = map$BestMatches[, 2]),
shape = 19, color = treeCols, size = 2)
} else {
message("Install the 'Umatrix' package to run this example")
}
```

```
## [1] "Epoch: 1 started"
## [1] "Epoch: 2 started"
## [1] "Epoch: 3 started"
## [1] "Epoch: 4 started"
## [1] "Epoch: 5 started"
## [1] "---- Esom Training Finished ----"
```

Blonder, B., Morrow, C. B., Maitner, B., Harris, D. J., Lamanna, C., Violle, C., … Kerkhoff, A. J. (2018). New approaches for delineating *n*-dimensional hypervolumes. *Methods in Ecology and Evolution*, *9*(2), 305–319. doi: 10.1111/2041-210X.12865

Kaufman, L., & Rousseeuw, P. J. (1990). Partitioning around medoids (Program PAM). In *Wiley Series in Probability and Statistics*. *Finding groups in data: An introduction to cluster analysis* (pp. 68–125). John Wiley & Sons, Ltd. doi: 10.1002/9780470316801.ch2

Kohonen, T. (1982). Self-organized formation of topologically correct feature maps. *Biological Cybernetics*, *43*(1), 59–69. doi: 10.1007/BF00337288

Kruskal, J. B. (1964). Multidimensional scaling by optimizing goodness of fit to a nonmetric hypothesis. *Psychometrika*, *29*(1), 1–27. doi: 10.1007/BF02289565

Mammola, S. (2019). Assessing similarity of *n*-dimensional hypervolumes: Which metric to use? *Journal of Biogeography*, *46*(9), 2012–2023. doi: 10.1111/jbi.13618

Sammon, J. W. (1969). A nonlinear mapping for data structure analysis. *IEEE Transactions on Computers*, *C-18*(5), 401–409. doi: 10.1109/T-C.1969.222678

Smith, M. R. (2020). Information theoretic Generalized Robinson-Foulds metrics for comparing phylogenetic trees. *Bioinformatics*, *36*(20), 5007–5013. doi: 10.1093/bioinformatics/btaa614

Smith, M. R. (2021). The importance of methodology when analysing landscapes of phylogenetic trees. *Forthcoming*.

Thrun, M. C., Lerch, F., Lötsch, J., & Ultsch, A. (2016). Visualization and 3D printing of multivariate data of biomarkers. *International Conference in Central Europe on Computer Graphics, Visualization and Computer Vision*. Plzen.

Ultsch, A. (2003). Maps for the visualization of high-dimensional data spaces. *Proceedings Workshop on Self-Organizing Maps (Wsom 2003)*, 225–230. Kyushu, Japan.
